Scope AR Markers are used for alignment purposes. If your project is configured to use a Scope AR marker, you will need a physical copy placed in your environment for content placement.

You can download Scope AR Image trackers below:

• Standard Scope AR Marker
• Numbered Scope AR Markers

Be sure to print the trackers at 100%, so that each tracker is 10 x 10 cm, corresponding to the size it has in the authored AR project.

Tip: For use on HL2, be sure you move the camera on the HL2 close enough to the target, as its resolution is not very high, it can struggle picking up the target from a further distance.



Is it possible to have multiple targets for Standalone Mode?

If you are wondering if it is possible to have two separate targets for standalone mode, the answer is "Yes".

You can have two targets that are standalone in different orientations but they would need to be unique for the image used.

To trigger a specific target to be used for AR placement, you need to be able to see the target physically in the real world. If you don't have one then the software will use the target that is set as the "Default target" for placing content.



Read more: WorkLink Work Instructions: Visibility Mode.
